Ubiquiti is known for its professional networking products, which are increasingly used in private homes. Access points from Ubiquiti make it possible to create a stable, fast and flexible wireless network that can cover everything from small apartments to large properties. But with several series and models on the market, it can be difficult to understand the differences and find the solution that best suits your needs.
In this article, you’ll get an overview of what to consider when choosing a Ubiquiti access point, as well as an introduction to the most important types and brands within wireless network solutions.
The article presents a selection of Ubiquiti access points representing different price ranges and areas of use – from compact models for the home to more advanced solutions for larger buildings. The aim is to provide an informative overview of features, specifications and possible applications. The information is based on publicly available product descriptions from manufacturers and retailers and is summarised to give a clear picture of the differences between the models.
Factors to consider when buying an access point
When choosing an access point, it’s not just about speed. Coverage, features and setup also play a major role. Here are some of the most important factors to take into account.
1. Coverage and number of access points
How large an area needs to be covered? One access point may be enough in a smaller home, while larger houses or properties often require several units placed strategically to ensure full coverage. Ubiquiti’s UniFi series makes it easy to expand the network with multiple devices that work together as one unified system.
2. Speed and standards
Most modern access points support Wi-Fi 6 (802.11ax), which provides higher speeds, better capacity and lower latency. If you have many connected devices or stream in high quality, it’s worth choosing a model with Wi-Fi 6 or newer technology.
3. Power supply and installation
Ubiquiti access points can often be powered via Ethernet (PoE), which means you only need one cable for both power and data. This makes installation easier and more flexible, especially if you want to mount the device on the ceiling or wall.
4. Central management and administration
One of Ubiquiti’s strengths is central management via the UniFi Controller software. Here you can monitor network performance, create guest networks and adjust settings for each access point. Consider whether you want this type of control or prefer a simpler solution.
5. Design and placement
Design can also play a role – especially if the access point will be placed visibly. Ubiquiti has models with discreet, minimalist designs that fit into modern homes. Correct placement is important for optimal coverage, so avoid hiding the device behind furniture or in cupboards.
Products in focus
The Ubiquiti UniFi UAP-AC-HD-5 is a set of five wireless access points developed to deliver fast and stable Wi-Fi coverage in larger network environments. Each unit supports dual-band operation with 2.4 GHz and 5 GHz frequency bands, providing flexibility and high total bandwidth.
The access point is based on the 802.11ac Wave 2 standard and can handle over 500 simultaneous clients, making it suitable for offices, educational institutions, and public areas with many users. The internal 4T4R MIMO technology contributes to efficient data transfer and a stable connection.
The devices can be centrally managed via Ubiquiti's UniFi Controller software, which allows monitoring, configuration, and scaling of the network. The design is discreet and can be mounted on both walls and ceilings, making installation flexible.
The set comes with mounting brackets but without PoE adapters, as the devices support PoE+ power supply via network cable. The low power consumption and wide operating temperature make them suitable for continuous operation in various environments.
- Dual-band performance: Supports both 2.4 GHz (up to 800 Mbps) and 5 GHz (up to 1.733 Mbps).
- High capacity: Can handle more than 500 simultaneous clients per unit.
- Advanced Wi-Fi 5 technology: 802.11ac Wave 2 with 4T4R MIMO for efficient data transfer.
- Central management: Compatible with UniFi Controller for easy setup and management.
- Flexible mounting: Can be installed on wall or ceiling and comes with mounting brackets.
Pros and cons
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Pros and cons
Pros
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
Cons
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Pros
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
Cons
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-HD-5
- EAN: 0810354026133
- Item number: 2581639
- Quantity per pack: 5 (specifications apply to single unit)
- Wireless standard: IEEE 802.11a/b/g/n/ac, 802.11ac Wave 2
- Frequency band: 2.4 GHz and 5 GHz
- Maximum data rate: 1.733 Gbps
- Capacity: Over 500 simultaneous clients, 1–4 BSSIDs per radio
- Antenna: Internal, 4 antennas
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- PoE support: PoE+ (802.3at)
- Power consumption: 17 W
- Dimensions: 22 × 22 × 4.81 cm
- Weight: 700 g
- Operating temperature: -10 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Compliance standards: IC, FCC, IEEE 802.1Q, 802.3af, 802.3at
Ubiquiti Rocket M365 is a wireless device developed for outdoor use, where stability and range are crucial. It supports the AirMax protocol, which enables efficient data transfer in both point-to-point and point-to-multipoint configurations.
The device is powered by an Atheros MIPS 24KC processor at 550 MHz and has 64 MB RAM as well as 8 MB flash memory, providing stable and fast operation. It is equipped with two RP-SMA antenna ports and a 100Base-TX RJ-45 port for network connection.
The Rocket M365 is designed to be pole-mounted and built to withstand outdoor conditions. It supports Power over Ethernet (PoE), which simplifies installation by combining power and data in one cable.
With a power consumption of 6.5 watts and a frequency band of 3.65 GHz, the device is suitable for professional wireless networks where reliable connection and flexible setup are required.
- Outdoor design: Robust construction for installation in demanding environments.
- AirMax protocol: Optimised for efficient wireless communication in professional networks.
- PoE support: Simplifies installation by combining power and data in one cable.
- Flexible mounting: Can be pole-mounted for optimal placement and signal strength.
- Low power consumption: Efficient operation with only 6.5 watts of consumption.
Pros and cons
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Pros and cons
Pros
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
Cons
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Pros
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
Cons
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Specifications
- Manufacturer: Ubiquiti
- Model: ROCKETM365
- Item number: 2666928
- EAN: 4250605598143
- Device type: Wireless connection (external, outdoor)
- Processor: 1 x Atheros MIPS 24KC 550 MHz
- RAM: 64 MB SDRAM
- Flash memory: 8 MB
- Data connection protocol: AirMax
- Frequency band: 3.65 GHz
- Power Over Ethernet (PoE): Supported
- Power consumption: 6.5 watts
- Interface: 2 x antenna (RP-SMA), 1 x 100Base-TX (RJ-45)
- Features: MIMO technology, QoS, pole mounting
- Dimensions (W x D x H): 16 × 8 × 3 cm
- Weight: 500 g
- Operating system: AirOS
Ubiquiti UniFi UAP-AC-SHD is an enterprise access point designed to deliver stable and fast wireless connectivity in demanding environments. The device supports both 2.4 GHz and 5 GHz frequency bands and can achieve speeds of up to 800 Mbps and 1733 Mbps, respectively.
The access point is based on Wi-Fi 5 (802.11ac Wave 2) and uses 4T4R MIMO technology to optimise signal strength and coverage. It can handle more than 500 simultaneous clients and supports features such as VLAN, QoS, and Wi-Fi Multimedia (WMM).
The device has built-in antennas and comes with mounting brackets, making it suitable for both wall and ceiling mounting. It is powered via PoE+ and has two Gigabit Ethernet ports, providing flexibility in installation.
With features such as Wireless Intrusion Prevention System (WIPS), airView, and Airtime Fairness, the UAP-AC-SHD is designed to deliver both high performance and advanced network security in professional environments.
- Dual-band performance: Supports both 2.4 GHz and 5 GHz with up to 1733 Mbps.
- Wi-Fi 5 (802.11ac Wave 2): Provides high capacity and efficient data handling.
- Advanced security: Includes WIPS and supports multiple encryption methods.
- Flexible installation: Can be mounted on wall or ceiling and powered via PoE+.
- High capacity: Supports over 500 simultaneous clients.
Pros and cons
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Pros and cons
Pros
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
Cons
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Pros
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
Cons
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-SHD
- Item number: 2626195
- EAN: 4250605500108
- Device type: Wireless connection (external)
- Wi-Fi standards: IEEE 802.11a/b/g/n/ac & ac Wave 2
- Frequency bands: 2.4 GHz and 5 GHz
- Maximum data rate: 1733 Mbps
- Capacity: Over 500 simultaneous clients, 1–4 BSSIDs per radio
- Antenna: Internal, 4 antennas
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- Power supply: PoE+ (17 W consumption)
- Dimensions: 22 × 22 × 4.81 cm
- Weight: 700 g
- Operating temperature: -10 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Compliance standards: IC, FCC, IEEE 802.1Q, 802.3af, 802.3at
Ubiquiti PrismStation PS-5AC is an outdoor access point that uses AirMax ac technology to deliver fast and stable wireless connectivity on the 5 GHz band. The device is built to withstand demanding environments and is therefore suitable for installations where reliability and signal strength are important.
The replaceable antenna horn makes it possible to focus the signal in a specific direction, reducing interference from other sources and improving noise immunity. This makes it particularly suitable for areas with many wireless signals.
The device is powered via Power over Ethernet (PoE), which simplifies installation as both power and data are transmitted through the same cable. It supports a data rate of up to 500 Mbps and is equipped with a MIPS 74KC processor and 128 MB DDR2 RAM.
With its modular design, AirOS 8 operating system, and features such as QoS, TPC, and airPrism technology, the PrismStation PS-5AC gives network administrators flexibility and control over wireless connections in professional environments.
- AirMax ac technology: Provides high data rates and efficient use of the 5 GHz band.
- Outdoor design: Robust construction that withstands temperatures from -40 °C to 70 °C.
- Modular antenna: Replaceable horn antenna with 14 dBi gain for focused signal direction.
- PoE support: Power and data via a single cable for easy installation.
- Advanced network features: Supports QoS, TPC, airPrism, and TDMA for optimised performance.
Pros and cons
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Pros and cons
Pros
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
Cons
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Pros
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
Cons
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Specifications
- Manufacturer: Ubiquiti
- Model: PS-5AC
- EAN: 817882022668
- Item number: 3083836
- Device type: Wireless connection (external, outdoor)
- Processor: 1 x MIPS 74KC
- RAM: 128 MB DDR2 SDRAM
- Data communication protocol: AirMax ac
- Frequency band: 5 GHz
- Data rate: Up to 500 Mbps
- Antenna: 1 pc, 14 dBi gain
- Interface: 1 x 1000Base-T (PoE) - RJ-45
- Power supply: PoE (Power over Ethernet), 10 W consumption
- Dimensions (W x D x H): 17.4 × 18.4 × 17.4 cm
- Weight: 1.07 kg
- Operating temperature: -40 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Operating system: AirOS 8
- Compliance standards: IC, FCC
Ubiquiti UniFi AC Mesh Professional UAP-AC-M-PRO is an enterprise access point developed for outdoor use. The device supports dual-band 802.11a/b/g/n/ac and delivers up to 450 Mbps on the 2.4 GHz band and up to 1300 Mbps on the 5 GHz band.
The weather-resistant housing makes it suitable for wall or pole mounting, and the built-in omnidirectional antennas ensure wide coverage in open environments. The device can be powered via 802.3af PoE or the included Gigabit PoE adapter.
The access point is centrally managed through the UniFi Controller software or via UniFi Cloud Key, allowing unified management of multiple devices, traffic monitoring and guest network setup.
The UAP-AC-M-PRO comes with mounting brackets, PoE adapter and necessary accessories, so installation can be carried out quickly and safely.
- Dual-band performance: Supports both 2.4 GHz and 5 GHz with up to 1750 Mbps total speed.
- Outdoor design: Robust construction that withstands wind and weather.
- 3x3 MIMO technology: Provides high capacity and stable connection for multiple users.
- Central management: Controlled via UniFi Controller or UniFi Cloud Key.
- Flexible power supply: Can be powered via 802.3af PoE or the included PoE adapter.
Pros and cons
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Pros and cons
Pros
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
Cons
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Pros
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
Cons
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-M-PRO
- Item number: 2574978
- EAN: 0810354024764
- Device type: Wireless connection (Wi-Fi 5)
- Form factor: External, outdoor
- Data communication protocols: IEEE 802.11a/b/g/n/ac
- Frequency band: 2.4 GHz and 5 GHz
- Maximum data rate: 450 Mbps (2.4 GHz) + 1300 Mbps (5 GHz)
- Maximum range: 183 metres
- Antennas: 3 internal, 8 dBi gain
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- Power supply: PoE+ (DC 44–57 V), 9 W consumption
- Dimensions (W x D x H): 18.12 × 6.02 × 34.32 cm
- Weight: 633 g
- Operating temperature: -40 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Supported operating systems: Linux, macOS, Windows 7/8/10
- Included equipment: PoE injector, mounting bracket, pole mount, screws
Product descriptions
The Ubiquiti UniFi UAP-AC-HD-5 is a set of five wireless access points developed to deliver fast and stable Wi-Fi coverage in larger network environments. Each unit supports dual-band operation with 2.4 GHz and 5 GHz frequency bands, providing flexibility and high total bandwidth.
The access point is based on the 802.11ac Wave 2 standard and can handle over 500 simultaneous clients, making it suitable for offices, educational institutions, and public areas with many users. The internal 4T4R MIMO technology contributes to efficient data transfer and a stable connection.
The devices can be centrally managed via Ubiquiti's UniFi Controller software, which allows monitoring, configuration, and scaling of the network. The design is discreet and can be mounted on both walls and ceilings, making installation flexible.
The set comes with mounting brackets but without PoE adapters, as the devices support PoE+ power supply via network cable. The low power consumption and wide operating temperature make them suitable for continuous operation in various environments.
- Dual-band performance: Supports both 2.4 GHz (up to 800 Mbps) and 5 GHz (up to 1.733 Mbps).
- High capacity: Can handle more than 500 simultaneous clients per unit.
- Advanced Wi-Fi 5 technology: 802.11ac Wave 2 with 4T4R MIMO for efficient data transfer.
- Central management: Compatible with UniFi Controller for easy setup and management.
- Flexible mounting: Can be installed on wall or ceiling and comes with mounting brackets.
Pros and cons
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Pros and cons
Pros
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
Cons
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Pros
- High performance and stability in environments with many users
- Supports modern Wi-Fi 5 (802.11ac Wave 2)
- Centralised management via UniFi Controller
- Flexible mounting and discreet design
- PoE+ power supply via network cable
Cons
- PoE adapters are not included and must be purchased separately
- Requires UniFi Controller for full functionality
- The product is discontinued and may be difficult to obtain
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-HD-5
- EAN: 0810354026133
- Item number: 2581639
- Quantity per pack: 5 (specifications apply to single unit)
- Wireless standard: IEEE 802.11a/b/g/n/ac, 802.11ac Wave 2
- Frequency band: 2.4 GHz and 5 GHz
- Maximum data rate: 1.733 Gbps
- Capacity: Over 500 simultaneous clients, 1–4 BSSIDs per radio
- Antenna: Internal, 4 antennas
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- PoE support: PoE+ (802.3at)
- Power consumption: 17 W
- Dimensions: 22 × 22 × 4.81 cm
- Weight: 700 g
- Operating temperature: -10 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Compliance standards: IC, FCC, IEEE 802.1Q, 802.3af, 802.3at
Ubiquiti Rocket M365 is a wireless device developed for outdoor use, where stability and range are crucial. It supports the AirMax protocol, which enables efficient data transfer in both point-to-point and point-to-multipoint configurations.
The device is powered by an Atheros MIPS 24KC processor at 550 MHz and has 64 MB RAM as well as 8 MB flash memory, providing stable and fast operation. It is equipped with two RP-SMA antenna ports and a 100Base-TX RJ-45 port for network connection.
The Rocket M365 is designed to be pole-mounted and built to withstand outdoor conditions. It supports Power over Ethernet (PoE), which simplifies installation by combining power and data in one cable.
With a power consumption of 6.5 watts and a frequency band of 3.65 GHz, the device is suitable for professional wireless networks where reliable connection and flexible setup are required.
- Outdoor design: Robust construction for installation in demanding environments.
- AirMax protocol: Optimised for efficient wireless communication in professional networks.
- PoE support: Simplifies installation by combining power and data in one cable.
- Flexible mounting: Can be pole-mounted for optimal placement and signal strength.
- Low power consumption: Efficient operation with only 6.5 watts of consumption.
Pros and cons
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Pros and cons
Pros
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
Cons
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Pros
- Robust construction for outdoor use
- Supports the AirMax protocol for high performance
- PoE makes installation easier
- Flexible mounting and compact design
- Suitable for both point-to-point and point-to-multipoint setups
Cons
- Limited to the 3.65 GHz frequency band
- Requires compatible AirMax components for full functionality
- The product is discontinued and may be difficult to obtain
Specifications
- Manufacturer: Ubiquiti
- Model: ROCKETM365
- Item number: 2666928
- EAN: 4250605598143
- Device type: Wireless connection (external, outdoor)
- Processor: 1 x Atheros MIPS 24KC 550 MHz
- RAM: 64 MB SDRAM
- Flash memory: 8 MB
- Data connection protocol: AirMax
- Frequency band: 3.65 GHz
- Power Over Ethernet (PoE): Supported
- Power consumption: 6.5 watts
- Interface: 2 x antenna (RP-SMA), 1 x 100Base-TX (RJ-45)
- Features: MIMO technology, QoS, pole mounting
- Dimensions (W x D x H): 16 × 8 × 3 cm
- Weight: 500 g
- Operating system: AirOS
Ubiquiti UniFi UAP-AC-SHD is an enterprise access point designed to deliver stable and fast wireless connectivity in demanding environments. The device supports both 2.4 GHz and 5 GHz frequency bands and can achieve speeds of up to 800 Mbps and 1733 Mbps, respectively.
The access point is based on Wi-Fi 5 (802.11ac Wave 2) and uses 4T4R MIMO technology to optimise signal strength and coverage. It can handle more than 500 simultaneous clients and supports features such as VLAN, QoS, and Wi-Fi Multimedia (WMM).
The device has built-in antennas and comes with mounting brackets, making it suitable for both wall and ceiling mounting. It is powered via PoE+ and has two Gigabit Ethernet ports, providing flexibility in installation.
With features such as Wireless Intrusion Prevention System (WIPS), airView, and Airtime Fairness, the UAP-AC-SHD is designed to deliver both high performance and advanced network security in professional environments.
- Dual-band performance: Supports both 2.4 GHz and 5 GHz with up to 1733 Mbps.
- Wi-Fi 5 (802.11ac Wave 2): Provides high capacity and efficient data handling.
- Advanced security: Includes WIPS and supports multiple encryption methods.
- Flexible installation: Can be mounted on wall or ceiling and powered via PoE+.
- High capacity: Supports over 500 simultaneous clients.
Pros and cons
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Pros and cons
Pros
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
Cons
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Pros
- High wireless performance with dual-band technology
- Supports many simultaneous users
- Advanced security features such as WIPS and VLAN
- PoE+ power supply for easy installation
- Compatible with UniFi Controller for central management
Cons
- Requires UniFi Controller software for full functionality
- Not suitable for small home networks as it is aimed at enterprise use
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-SHD
- Item number: 2626195
- EAN: 4250605500108
- Device type: Wireless connection (external)
- Wi-Fi standards: IEEE 802.11a/b/g/n/ac & ac Wave 2
- Frequency bands: 2.4 GHz and 5 GHz
- Maximum data rate: 1733 Mbps
- Capacity: Over 500 simultaneous clients, 1–4 BSSIDs per radio
- Antenna: Internal, 4 antennas
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- Power supply: PoE+ (17 W consumption)
- Dimensions: 22 × 22 × 4.81 cm
- Weight: 700 g
- Operating temperature: -10 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Compliance standards: IC, FCC, IEEE 802.1Q, 802.3af, 802.3at
Ubiquiti PrismStation PS-5AC is an outdoor access point that uses AirMax ac technology to deliver fast and stable wireless connectivity on the 5 GHz band. The device is built to withstand demanding environments and is therefore suitable for installations where reliability and signal strength are important.
The replaceable antenna horn makes it possible to focus the signal in a specific direction, reducing interference from other sources and improving noise immunity. This makes it particularly suitable for areas with many wireless signals.
The device is powered via Power over Ethernet (PoE), which simplifies installation as both power and data are transmitted through the same cable. It supports a data rate of up to 500 Mbps and is equipped with a MIPS 74KC processor and 128 MB DDR2 RAM.
With its modular design, AirOS 8 operating system, and features such as QoS, TPC, and airPrism technology, the PrismStation PS-5AC gives network administrators flexibility and control over wireless connections in professional environments.
- AirMax ac technology: Provides high data rates and efficient use of the 5 GHz band.
- Outdoor design: Robust construction that withstands temperatures from -40 °C to 70 °C.
- Modular antenna: Replaceable horn antenna with 14 dBi gain for focused signal direction.
- PoE support: Power and data via a single cable for easy installation.
- Advanced network features: Supports QoS, TPC, airPrism, and TDMA for optimised performance.
Pros and cons
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Pros and cons
Pros
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
Cons
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Pros
- High performance and stable connection on the 5 GHz band
- Robust construction for outdoor use
- Flexible antenna solution with replaceable horn
- PoE power supply for easy installation
- Advanced network features for professional use
Cons
- Requires compatible PoE injector or switch
- Directional antenna requires precise mounting for optimal coverage
Specifications
- Manufacturer: Ubiquiti
- Model: PS-5AC
- EAN: 817882022668
- Item number: 3083836
- Device type: Wireless connection (external, outdoor)
- Processor: 1 x MIPS 74KC
- RAM: 128 MB DDR2 SDRAM
- Data communication protocol: AirMax ac
- Frequency band: 5 GHz
- Data rate: Up to 500 Mbps
- Antenna: 1 pc, 14 dBi gain
- Interface: 1 x 1000Base-T (PoE) - RJ-45
- Power supply: PoE (Power over Ethernet), 10 W consumption
- Dimensions (W x D x H): 17.4 × 18.4 × 17.4 cm
- Weight: 1.07 kg
- Operating temperature: -40 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Operating system: AirOS 8
- Compliance standards: IC, FCC
Ubiquiti UniFi AC Mesh Professional UAP-AC-M-PRO is an enterprise access point developed for outdoor use. The device supports dual-band 802.11a/b/g/n/ac and delivers up to 450 Mbps on the 2.4 GHz band and up to 1300 Mbps on the 5 GHz band.
The weather-resistant housing makes it suitable for wall or pole mounting, and the built-in omnidirectional antennas ensure wide coverage in open environments. The device can be powered via 802.3af PoE or the included Gigabit PoE adapter.
The access point is centrally managed through the UniFi Controller software or via UniFi Cloud Key, allowing unified management of multiple devices, traffic monitoring and guest network setup.
The UAP-AC-M-PRO comes with mounting brackets, PoE adapter and necessary accessories, so installation can be carried out quickly and safely.
- Dual-band performance: Supports both 2.4 GHz and 5 GHz with up to 1750 Mbps total speed.
- Outdoor design: Robust construction that withstands wind and weather.
- 3x3 MIMO technology: Provides high capacity and stable connection for multiple users.
- Central management: Controlled via UniFi Controller or UniFi Cloud Key.
- Flexible power supply: Can be powered via 802.3af PoE or the included PoE adapter.
Pros and cons
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Pros and cons
Pros
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
Cons
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Pros
- High wireless speed and range
- Suitable for outdoor installations
- Easy integration into UniFi networks
- Supports both wall and pole mounting
- Comes with PoE adapter and mounting equipment
Cons
- Requires UniFi Controller for configuration and operation
- Not suitable for use outside the UniFi ecosystem
Specifications
- Manufacturer: Ubiquiti
- Model: UAP-AC-M-PRO
- Item number: 2574978
- EAN: 0810354024764
- Device type: Wireless connection (Wi-Fi 5)
- Form factor: External, outdoor
- Data communication protocols: IEEE 802.11a/b/g/n/ac
- Frequency band: 2.4 GHz and 5 GHz
- Maximum data rate: 450 Mbps (2.4 GHz) + 1300 Mbps (5 GHz)
- Maximum range: 183 metres
- Antennas: 3 internal, 8 dBi gain
- Interface: 2 x 1000Base-T (PoE+) RJ-45
- Power supply: PoE+ (DC 44–57 V), 9 W consumption
- Dimensions (W x D x H): 18.12 × 6.02 × 34.32 cm
- Weight: 633 g
- Operating temperature: -40 °C to 70 °C
- Humidity: 5–95% (non-condensing)
- Supported operating systems: Linux, macOS, Windows 7/8/10
- Included equipment: PoE injector, mounting bracket, pole mount, screws
Different types of access points
Access points come in many variants that differ in features, capacity and area of use. Knowing the difference can help you choose the right type for your network.
1. Indoor access points
These models are designed to provide stable Wi-Fi coverage in the home or office. They are typically mounted on the ceiling or wall and are ideal for general use, streaming and gaming. The Ubiquiti UniFi series includes several popular indoor models.
2. Outdoor access points
Outdoor access points are built to withstand weather and wind and are used to extend the network to the garden, terrace or outdoor work areas. They often have higher transmission power and longer range.
3. Mesh access points
Mesh systems consist of several devices that work together to create a seamless network. This type is ideal if you want easy setup and even coverage without dead zones. Ubiquiti offers mesh-compatible models that can be integrated into existing UniFi networks.
4. Enterprise access points
These models are intended for larger installations such as office buildings, schools or hotels. They have advanced features such as VLAN support, multiple SSIDs and high capacity. Although they can be used at home, they are often more expensive and require more technical setup.
Different brands of access points
Although Ubiquiti is a popular choice, there are several manufacturers offering solid alternatives with different strengths and areas of focus.
TP-Link (Omada)
TP-Link offers both consumer and business solutions. Their Omada series is similar to Ubiquiti’s UniFi with central management and good scalability. TP-Link is often affordable and easy to set up.
Netgear (Insight and Orbi)
Netgear offers both professional access points and user-friendly mesh solutions such as Orbi. They are known for stability and high performance, especially in homes with many devices.
Aruba (Hewlett Packard Enterprise)
Aruba is a premium brand focusing on security and advanced network management. The products are primarily aimed at businesses but are also used in advanced home networks.
Cisco
Cisco is one of the most recognised manufacturers in network technology. Their access points offer high reliability but often require more technical knowledge to configure.
MikroTik
MikroTik offers flexible and affordable network solutions for both private and professional users. The products are known for many configuration options and high performance for the price.
Frequently asked questions
What is the difference between a router and an access point?
A router distributes the internet connection to multiple devices and handles IP addresses, while an access point simply extends the wireless network. Many choose to combine a good router with several access points for better coverage.
How many access points do I need?
It depends on the size of the home and the materials of the walls. A typical flat can often be covered with one access point, while a larger house usually requires two or more for optimal coverage.
Can I use Ubiquiti access points without UniFi Controller?
Yes, some models can operate independently, but you’ll get the most out of them by using UniFi Controller or Cloud Key, which provides access to advanced features and easy management.
Do Ubiquiti access points support guest networks?
Yes, most models allow you to create separate guest networks with their own access rules, so visitors can get internet access without accessing your private network.
Is it difficult to install an access point?
Most modern access points, including Ubiquiti’s models, are designed for easy setup via app or web interface. If you use PoE, however, installation requires that you have a PoE switch or adapter.
Læs også:
